Bose Professional ControlSpace EX-1280 Digital Signal Processor

Name: Bose Professional ControlSpace EX-1280 Digital Signal Processor
Brand: Bose Professional
SKU: EX 1280
Price: 15167.25 AED
Availability: InStock

Brand Bose Professional

15,167.25 AED Includes 5% UAE VAT

The EX-1280 serves as a centralized brain for sound systems, offering a flexible platform that integrates seamlessly with Bose loudspeakers, wall controllers, and third-party Dante-enabled devices. Its open-architecture design allows system integrators to use ControlSpace Designer software for drag-and-drop programming of signal processing modules, making it suitable for both small projects and large, networked systems.

Ask a question

Model number EX 1280

Availability In Stock

Enquire on WhatsApp

UAE delivery
Timing confirmed at checkout.

Compatibility support
Expert product matching.

Secure payment
Protected checkout in AED.

Secure checkoutProtected payments in AED

Description

Key Features

Flexible I/O Configuration: Features 12 balanced mic/line analog inputs and 8 analog outputs.
High-Capacity Dante Networking: Equipped with a 64 × 64 Dante network audio interface for low-latency digital audio across large networks.
AmpLink Output: Includes a dedicated port for 8 channels of uncompressed, low-latency digital audio directly to compatible Bose Professional amplifiers.
Front-Panel Control: A large 256 × 64 OLED display and rotary encoder allow for monitoring channel activity and configuring network parameters directly from the hardware.
Advanced Control Options: Supports GPIO (5 in/5 out) for external interfaces such as microphone pushbuttons or status LEDs, alongside serial RS-232 and RS-485 connections.

Applications

The EX-1280 is optimized for a variety of commercial and professional environments, including:

Performance Venues and Stadiums: For large-scale sound reinforcement and complex routing.
Houses of Worship: To manage multiple zones and high-quality mic inputs.
Hospitality and Resorts: For multi-zone background and foreground music distribution.
Corporate Multipurpose Spaces: Handling varied audio needs across divisible rooms.
Courtrooms: Where reliable, secure audio routing and local voice lift are essential.

Specifications

DSP Section	Signal Processor/CPU: 32-Bit Fixed / Floating-Point DSP + ARM, 456 MHz Maximum Calculation: 3.6 GIPS / 2.7 GFLOPS Delay: 43 s Audio Latency: 1.05 ms (Analog In to Analog Out, Without AEC) A/D and D/A Converters: 24-Bit Sample Rate: 48 kHz
Analog Audio Inputs	Input Channels: 12 Balanced, Mic/Line Level Connectors, Input: 0.15″ / 3.81 mm Detachable Euroblock, 6-Pin Input Impedance: 12 Kilohms at 1 kHz (with or without Phantom Power Active) Maximum Input Level: +24 dBu Equivalent Input Noise: -118 dB at 44 dB Gain Setting Phantom Power: +48 VDC, 10 mA, Selectable per Input Pre-Gain Settings: 0/14/24/32/44/54/64 dB
Analog Audio Outputs	Output Channels: 8 Analog (Balanced, Line Level) Connectors, Output: 0.15″ / 3.81 mm Euroblock, 6-Pin Output Impedance: 200 Ohms Maximum Output Level: +24 dBu
Audio Performance	Frequency Response 18 Hz to 20 kHz (+0.8 dB/-0.2 dB Ref 1 kHz) THD+N: < 0.003% at +4 dBu (A-weighted/20 Hz to 18 kHz) < 0.01% at +44 dBu (A-weighted/20 Hz to 18 kHz) Channel Separation (Crosstalk): < -105 dB at +4 dBu 1 kHz Input Signal Dynamic Range > 115 dB, A-weighted 20 Hz – 20 kHz, Analog Input to Analog Output
Audio Over IP	Dante: 64 x 64, Primary/Secondary
Digital Audio Outputs	AmpLink (Output Only): 8 Low Latency (< 21µs), 48 kHz (Requires shielded Cat 5/6) USB Device: Micro-B Type, Stereo In/Out USB Host: Type A (For Future Use)
Control Inputs	Inputs (Control): 5 Analog or Digital Inputs, 2 Kilohms Internal Pull-Up Resistor to 5 V, 0.15″ / 3.81 mm Detachable Euroblock, 6-Pin Analog Input Voltage Range: 0 to 3.3 V (Maximum 5 V) Digital Input Voltage Range: 0 V to 3.3 V (Threshold Voltage = 1.6 V)
Control Output	Outputs (Control): 5 Digital Outputs, 0.15″ / 3.81 mm Detachable Euroblock, 6-Pin Output Voltage High: 8 V (Open Circuit), 2.5 V at 10 mA; Low: <1 V at 100 mA, Push Pull
Indicators & Controls	Display: 256 x 64 OLED with Rotary Encoder LED Status Indicators: Power/Status Audio Signal Indication: On Display
General	PC Configuration Software: ControlSpace Designer Software Version 5.5 or Later Network Control: Ethernet (RJ-45), 1 Gbps RS-232/485 Ports: RS-232 (DTE) and Bose CC-16 (RS-485 Master) 0.15″ / 3.81 mm Detachable Euroblock, 3-Pin
Operating Temperature	32 to 104°F / 0 to 40°C
Cooling System	2 Variable-Speed Fans, Side Venting
Compliance	Safety: UL60065 (8th Edition), CAN/CSA-C22.2 No.60065 (8th Edition), IEC/EN60065 (8th Edition) UL62368-1 (2nd Edition), CAN/CSA C22.2 No. 62368-1-14 (2nd Edition), IEC/EN 62368-1 (2nd Edition) EMC: EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55035:2017 FCC Part 15B Class A, AS/NZS CISPR 32:2015, ICES-003 Class A, CISPR13
Power	Mains Voltage: 85 to 264 VAC 50/60 Hz AC Power Consumption: 35 W Typical at 104 °F (40 °C) Ambient Mains Connector: IEC 60320-C14 (Inlet) Power Dissipation: 60 W (205 BTU, 52 kcal)
Dimensions	1.7 x 19.0 x 11.1″ / 4.3 x 48.3 x 28.2 cm
Weight	7.1 lb / 3.2 kg
