Tannoy VX 12.2Q 12-Inch PowerDual Loudspeaker 2000W Peak for High SPL
5,175.45 AED Includes 5% UAE VAT
The VX 12.2Q is a high-performance loudspeaker that delivers impressive high SPL and low distortion audio, ideal for medium-to-large sound reinforcement in venues like bars and clubs, as well as for mid-scale live events. Featuring twin driver design for extended low frequency reproduction and versatile mounting options, it excels in both portable and installed setups and supports bi-amp configuration.
Model number
VX 12.2Q
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
VX 12.2Q Loudspeaker
The VX 12.2Q is a powerful and versatile loudspeaker designed for high SPL applications such as clubs, bars, and live PA setups. Its twin driver design and multiple mounting options offer excellent flexibility, making it suitable for both portable and installed systems. With the ability to switch to bi-amp operation, the VX 12.2Q delivers exceptional audio performance.
Key Features
- Full range multi-purpose sound reinforcement loudspeaker
- 500 Watts continuous, 2,000 Watts peak power
- 12″ PowerDual full range driver for point source phase coherence
- 12″ low frequency driver for extended bass response
- Q-Centric waveguide for tighter vertical or horizontal pattern control
- Precise 75° H x 40° V dispersion for optimum coverage
- Configurable for bi-amp operation
- Durable plywood enclosure with semi-matt black paint finish
- Rugged powder-coated perforated steel mesh grille
- Neutrik speakON NL4 and barrier strip connectors
- Optional horizontal and vertical mounting yokes
Specifications
| Specification | Details |
|---|---|
| Frequency Response | 70 Hz – 25 kHz ±3 dB, 55 Hz – 30 kHz -10 dB |
| Nominal Dispersion | 75° H x 40° V @ -6 dB points |
| Directivity Factor (Q) | 13 |
| Directivity Index (DI) | 11.1 |
| Power Handling (Passive) | 500 W continuous, 2,000 W peak |
| Power Handling (Bi-amp) | LF: 350 W continuous, 1,400 W peak; MF/HF: 350 W continuous, 1,400 W peak |
| Sensitivity | 99 dB (1 W @ 1 m) |
| Maximum SPL (Passive) | 126 dB continuous, 132 dB peak |
| Maximum SPL (Bi-amp) | LF: 123 dB continuous, 129 dB peak; HF: 127 dB continuous, 133 dB peak |
| Impedance | Passive: 8 Ω; Bi-amp: 8 Ω LF, 8 Ω HF |
| Crossover Type | Passive / Bi-amp switchable |
| Components | 1 x 12″ PowerDual, 1 x 12″ LF driver |
| Connectors | 2x Neutrik speakON NL4, 1 x barrier strip terminals |
| Wiring (Passive) | Pins 1+ / 1- Input, Pins 2+ / 2- Link |
| Wiring (Bi-amp) | Pins 1+ / 1- LF, Pins 2+ / 2- HF |
| Dimensions (H x W x D) | 781 x 371 x 361 mm (30.7 x 14.6 x 14.2″) |
| Net Weight | 30.5 kg (67.2 lbs) |
| Construction | 15 mm (5/8″) plywood enclosure, 18 mm (3/4″) front, vented and internally braced |
| Finish | Semi matt black paint |
| Grille | Powder coated perforated steel |
| Flying Hardware | M10 x 8 inserts, yoke bracket inserts, 2 Integrip handles |
| Accessories | Optional yokes for horizontal and vertical mounting |
