Tannoy CVS 801S LZ 8″ In-Ceiling Subwoofer, 400W Peak, Low Impedance
934.50 AED Includes 5% UAE VAT
The CVS 801S LZ is an 8 Ohm ceiling subwoofer designed to deliver exceptional audio in both background and foreground music systems, ideal for use in restaurants, hotels, houses of worship, and businesses. It features high power handling, extended bass output, and low distortion. The subwoofer is UL 1480 certified for fire-protected signaling and UL 2043 certified for air-handling spaces, ensuring it meets key safety standards.
Model number
CVS 801S LZ
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
CVS 801S LZ Ceiling Subwoofer
The CVS 801S LZ is a low impedance (8 Ohms) ceiling subwoofer engineered to provide superb audio performance in both background and foreground music sound systems. Ideally suited for a wide variety of applications, from restaurants and hotels to houses of worship and businesses of all types, the CVS 801S LZ offers the power handling, extended bass output and low distortion typically found in more expensive products. UL 1480 certification for fire-protected signalling systems and UL 2043 for air-handling spaces make the CVS 801S LZ the perfect choice where safety is a top priority.
Key Features
- 100 Watts continuous, 400 Watts peak power
- 8″ polypropylene long-excursion driver with butyl rubber surround
- Extended deep bass output
- UL 1480 certified for fire-protected signalling systems
- UL 2043 certified for air-handling spaces
- UV and weather resistant UL 94 V-0 ABS front with plated steel fire can enclosure
- Powder coated aluminium mesh grille with dust protection
- Acoustic low-pass baffle design allows use without crossover
- Semi matt white finish fits unobtrusively in any environment
Specifications
| Specification | Details |
|---|---|
| Frequency Response (+3dB, -3 dB) | 66 Hz-200 Hz |
| Frequency Response (-10 dB) | 53 Hz-200 Hz |
| Sensitivity at 1m/1W | 92 dB |
| Power Handling (LoZ) | 100 W Average, 200 W Programme, 400 W Peak |
| Recommended Amplifier Power | 200 W @ 8 Ω |
| Nominal Impedance | 8 Ω |
| Rated Maximum SPL | 115 dB |
| Average SPL | 112 dB |
| Peak SPL | 118 dB |
| Low Frequency Transducer | 200 mm (8″) Paper cone |
| Enclosure | Blind mount (BM), Anodized steel |
| Baffle | Reflex loaded UL 94V-0 rated ABS |
| Grille | Aluminum, powder coated |
| Safety Features | Rear enclosure safety ring for load-bearing bond |
| Clamping Design | Security toggle clamp |
| Connectors | Euroblock-style connector with screw terminals |
| Bezel Diameter | 305 mm (12″) |
| Rear Baffle to Rear Can | 292.50 mm (11.52″) |
| Hole Cutout Diameter | 273 mm (10.75″) |
| Net Weight | 7 kg (15.4 lbs) ±10% |
| Included Accessories | Metal grille, cable gland, flex conduit, C-ring, tile-bridge kit, paint mask, cutout template |
| Optional Accessories | Mud ring, 48″ Tile rail |
