Lab Gruppen D 40:4L 4000W 4-Channel Amplifier with Lake DSP and Dante Networking
17,803.80 AED Includes 5% UAE VAT
The D 40:4L combines 4000 W of flexible power with advanced LAKE DSP, DANTE digital audio networking, and system integrity monitoring. Built on the robust amplifier technologies of the PLM Series, it offers proven reliability and exceptional sonic performance for demanding concert tours and large-scale installations.
Model number
D 40:4L
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
D 40:4L Professional Audio Amplifier
The D 40:4L amplifier offers 4000 W of flexible power, enhanced with the latest LAKE DSP technology, DANTE digital audio networking, and advanced system integrity monitoring capabilities. Engineered with the same high-power technologies as the renowned PLM Series, the D 40:4L is ideal for rigorous concert tours and large-scale installations.
Features
- 4000 Watt amplifier with 4 output channels, each channel supporting up to 2000 Watts
- Lake DSP for superior loudspeaker management and system control
- Integrated 8×8 channels of dual redundant Dante digital audio networking with AES67 support
- Robust power handling capabilities, including low and high impedance configurations
- Class D output stage with direct drive 70 and 100 V systems
- Rational Power Management (RPM) for efficient power allocation across channels
- Power Factor Correction (PFC) and switch mode power supply for cost and energy efficiency
- Breaker Emulation Limiter (BEL) for protection against mains breaker tripping
- Advanced energy-saving features including Auto Power Down and Adaptive Rail Control
- On-board load monitoring and surveillance for system integrity and emergency applications
- CAFE software for comprehensive system design and management
- Seamless integration with third-party matrix systems
- Detachable dust filter grille for maintenance
- Slimline 1U rackmount chassis with rear support brackets
Specifications
| Specification | Details |
|---|---|
| Processing / Network | Lake / Dante |
| Number of amplifier channels | 4 |
| Total burst power (all channels) | 4000 W |
| Max output power per channel | 2 ohms: 800 W, 2.67 ohms: 1000 W, 4 ohms: 1000 W, 8 ohms: 1000 W, 16 ohms: 700 W |
| High Voltage Configurations | Hi-Z 25 V: 500 W, Hi-Z 70 V: 1000 W, Hi-Z 100 V: 1000 W |
| Amplifier Output Peak Voltage | 150 Vpk |
| Amplifier Output Max Current | 30 Apk |
| Protection Features | Includes CAL, VHF, DC, Short Circuit Protection, and Temperature Protection |
| Dynamic Range | > 112 dB |
| Internal Sample Rate | 96 kHz / 32 bit floating point |
| Dante I/O | 8 x 8 |
| AES Inputs | 4, supporting sample rates up to 192 kHz |
| Analog Inputs | 4 high-quality inputs with Iso-Float ground isolation |
| Dimensions | W: 483 mm (19″), H: 44 mm (1 U), D: 425 mm (16.7″) |
| Weight | 8.3 kg (18.3 lbs) |
| Finish | Black painted steel chassis with grey detachable grille |
| Approvals | CE, ETL (ANSI/UL, CSA), PSE, RCM, BIS, CCC |
