JBL Professional CSA1300Z 300W Single Channel Commercial Amplifier
3,139.50 AED Includes 5% UAE VAT
The JBL CSA 1300Z Single-Channel 300W Amplifier is designed for installed sound applications, featuring Crown's DriveCore technology for powerful and efficient performance. It supports low impedance, 70V, and 100V outputs and includes a rack mounting kit and RJ45 connector for optional remote volume control with the JBL CSR-V control module.
Model number
CSA1300Z
Availability
In Stock
UAE delivery
Timing confirmed at checkout.
Timing confirmed at checkout.
Compatibility support
Expert product matching.
Expert product matching.
Secure payment
Protected checkout in AED.
Protected checkout in AED.
Secure checkoutProtected payments in AED
Description
Description
Built for installed sound applications, the CSA 1300Z Single-Channel 300W Amplifier from JBL delivers powerful sound and efficient performance using Crown’s DriveCore commercial power amplifier technology. Simple to configure, this amplifier provides a DriveCore-based sound solution, which utilizes one small chip that significantly reduces the part count and increases reliability while still maintaining high performance. It provides amplification with a choice of low impedance, 70V or 100V outputs. The amp includes a rack mounting kit for installations to a cabinet, and a RJ45 connector for an optional remote volume control using JBL’s CSR-V control module.
Key Features
- One channel with 300W output
- Integrated output transformer to drive 70V or 100V speaker systems
- Ideal for commercial and industrial use
- Euroblock style input connectors
- Barrier strip output connectors
- Independent bass and treble controls for each output channel
- Remote volume control capability using JBL’s CSR-V module and standard Ethernet cable (sold separately)
- Space-saving 2 RU design
- Capable of RS232 control of volume, stand-by, and mute
- Utilizes Crown’s DriveCore technology providing high-quality audio performance with high efficiency
- Sleep mode disable function
- Energy-efficient amplifier
- Sleek look with illuminated rings making knobs easy to see and use
- System can be expanded by adding JBL Commercial Series Mixers and Mixer-Amplifiers (sold separately)
Specifications
| Specification | Details |
|---|---|
| Number of Channels | 1 |
| Power Rating | 4 Ohms / 8 Ohms: 300 W (1 kHz, 0.5% THD) |
| Load Impedance / Voltage | 4 Ohms (Minimum), 70 / 100 V |
| Frequency Response | 20 Hz to 20 kHz ±1 dB (8 Ohms) |
| Input Sensitivity | Line: 775 mVrms (Balanced, at 8 Ohms), RCA: 300 mV (at 8 Ohms) |
| Input Impedance | Euroblock: 20 Kilohms (Balanced), RCA: 10 Kilohms |
| SNR | > 97 dBA |
| THD | < 0.5% (Full Range, at Rated Power) |
| Crosstalk | < -70 dBA (1 kHz) |
| EQ | 2-Band |
| I/O | Euroblock Balanced/Unbalanced Input, 2RCA Summed-Mono Input, Terminal Block Output |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Operating Temperature | 32 to 95°F / 0 to 35°C |
| Storage Temperature | -4 to 185°F / -20 to 85°C |
| Dimensions | 17.0 x 11.0 x 3.5″ / 43.0 x 27.0 x 8.9 cm |
| Weight | 13.1 lb / 5.9 kg |
| Package Weight | 15.7 lb |
| Box Dimensions (LxWxH) | 21.6 x 14.5 x 6″ |
