D.A.S. Audio ALTEA-DUO-10A Active 500W 10″ 3-Way Portable Column Loudspeaker System (Black)

Name: D.A.S. Audio ALTEA-DUO-10A Active 500W 10" 3-Way Portable Column Loudspeaker System (Black)
Brand: D.A.S Audio
SKU: ALTEA-DUO-10A
Price: 3913.35 AED
Availability: InStock

D.A.S Audio Brand D.A.S Audio

3,913.35 AED Included (5% UAE VAT)

The DAScontrol technology onboard offers adjustable 24-bit DSP via the LCD interface, letting you select between three voicing presets for different applications, as well as 3-band EQ control. You can adjust input gain for the three input channels on the rear panel. Stereo audio can be wirelessly streamed via Bluetooth and the DASLink GM app. I/O includes two XLR-1/4" combo input jacks for mic/line/Hi-Z signals, one 1/4" TRS Hi-Z input, a 3.5mm aux input, and an XLR 3-pin thru connection. With efficient power consumption, this system consumes as little energy as possible when taken to an event. The ALTEA-DUO-10A includes a carrying bag for the top three units and a cover for the subwoofer.

Ask a question

Model number ALTEA-DUO-10A

Availability In Stock

Enquire on WhatsApp

UAE delivery
Timing confirmed at checkout.

Compatibility support
Expert product matching.

Secure payment
Protected checkout in AED.

Secure checkoutProtected payments in AED

Description

The DAScontrol technology onboard offers adjustable 24-bit DSP via the LCD interface, letting you select between three voicing presets for different applications, as well as 3-band EQ control. You can adjust input gain for the three input channels on the rear panel. Stereo audio can be wirelessly streamed via Bluetooth and the DASLink GM app. I/O includes two XLR-1/4″ combo input jacks for mic/line/Hi-Z signals, one 1/4″ TRS Hi-Z input, a 3.5mm aux input, and an XLR 3-pin thru connection. With efficient power consumption, this system consumes as little energy as possible when taken to an event. The ALTEA-DUO-10A includes a carrying bag for the top three units and a cover for the subwoofer.

Flexible Amplifier System with DSP

The two-channel Class-D amplifier and universal power supply with 1000W peak power provides the power and dynamics that such an ultralightweight-system requires. The DSP board incorporates DAScontrol technology with LCD display and a rotary knob for selecting multiple acoustic modes (presets) depending on how the system is used as well as access to other configurable options within the system’s menu.

The DSP incorporates two independent mic/line inputs with their respective volume settings, plus a third instrument input designed for connecting keyboards, basses, or guitars. Stereo audio can be sent wirelessly from mobile devices and the entire system can be controlled with the DASlink GM app.

Powerful Sound Reproduction

The system incorporates one 10″ 10MG speaker developed specifically for low-frequency reproduction with ultralow-distortion levels via a powerful magnetic assembly and a cone suspension design with high-displacement capability. To reproduce mid and high frequencies, the top system features two 3″ 3PN drivers with neodymium magnets and an M27N (1″) neodymium compression driver coupled to a 100 x 50° horn. The horizontal directional control of the system provided by the horn is highly uniform across the entire high-frequency spectrum and the compression driver ensure that the highs are bright and defined.

Specification

Speaker Configuration	3-Way Speaker Column with Subwoofer
Number of Input Channels	3 (2 x Mono, 1 x Stereo)
Amplifier Power Rating	HF: 100 W Program 200 W Peak LF: 400 W Program 800 W Peak
HF Driver	1x 1″ / 2.5 cm Compression Driver
MF Driver	2x 3″ / 7.6 cm
Audio I/O	Combo XLR-1/4″ / XLR / 1/8″ (3.5 mm)
USB I/O	No
Wireless	Bluetooth

Portable PA System

Speaker Configuration	3-Way Speaker Column with Subwoofer
Number of Input Channels	3 (2 x Mono, 1 x Stereo)
Amplifier Power Rating	HF: 100 W Program 200 W Peak LF: 400 W Program 800 W Peak
Amplifier Class	Class-D

Speakers

Enclosure Type	Bass-Reflex
HF Driver	1x 1″ / 2.5 cm Compression Driver
HF Voice Coil	1″ / 2.5 cm
MF Driver	2x 3″ / 7.6 cm
MF Voice Coil	0.75″ / 1.91 cm
Subwoofer Driver	1x 10″ / 25.4 cm Woofer
Subwoofer Voice Coil	2″ / 5.1 cm
Magnet	HF Driver/MF Driver: Neodymium Subwoofer: Ferrite

Signal Processing

EQ	3-Band Graphic
Semi-Parametric EQ	No
Effects	3x Voicing Preset
DSP	Yes: 24-Bit DSP
Filters	No
Dynamic Processing	No

Performance

Frequency Range	40 Hz to 20 kHz -10 dB
Maximum SPL	124 dB SPL
Coverage Angle	100° H x 50° V
Coverage Angle	Omnidirectional
I/O Impedance	Input: 20 Kilohms

Connectivity

Audio I/O	2x Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input 1x 1/4″ TRS Hi-Z Input 1x 1/8″ / 3.5 mm TRS Aux Input 1x XLR 3-Pin Speaker Thru
Phantom Power	+48 V
USB I/O	No
Mobile App Compatible	Yes: Android & iOS App Name: DASLink GM Functionality: Adjust Settings, Remote Control
Network I/O	No

Wireless

Bluetooth

Power

AC Input Power	115 VAC, 50 / 60 Hz
Current Consumption	3 A

Physical

Transport Options	Handle (Bottom)
Construction Material	ABS, Polypropylene, Wood
Environmental Resistance	No
Dimensions	78 x 15.7 x 15.2″ / 198.1 x 39.9 x 38.6 cm
Weight	55 lb / 24.9 kg
