Bose Professional CSP-1248 Commercial Sound Processor

Name: Bose Professional CSP-1248 Commercial Sound Processor
Brand: Bose Professional
SKU: CSP 1248
Price: 7830.90 AED
Availability: InStock

Brand Bose Professional

7,830.90 AED Includes 5% UAE VAT

Ask a question

Model number CSP 1248

Availability In Stock

Enquire on WhatsApp

UAE delivery
Timing confirmed at checkout.

Compatibility support
Expert product matching.

Secure payment
Protected checkout in AED.

Secure checkoutProtected payments in AED

Description

The ControlSpace CSP-1248 is a 1RU fixed-architecture commercial sound processor designed for medium-to-large commercial audio installations. It provides a higher density of inputs and outputs than smaller models in the line, offering an efficient, pre-configured DSP workflow. The unit uses an internal web server that hosts a browser-based configuration utility, enabling fast system setup, routing, source prioritization, and tuning via any standard PC or Mac network connection without requiring external application downloads.

Features

AutoVolume Compensation: Dynamically tracks room ambient noise when paired with separate sense microphones, automatically scaling zone output volumes to preserve clarity during high-traffic business hours.
SmartBass Processing: Delivers targeted low-frequency management that optimizes loudspeaker low-end response, ensuring warm, punchy bass performance across all listening volumes.
Opti-Voice Paging & Opti-Source Management: Smoothly ducks music signals during high-priority announcements and handles gain balancing between varying media inputs to avoid sudden volume jumps.
AmpLink Digital Port: Employs an RJ-45 digital interface to pass 8 channels of uncompressed, low-latency audio straight to compatible digital power amplifiers over standard category cabling.
Scheduling and External Control: Features an internal clock scheduler to automate volume changes and source configurations based on time of day. Fully supports digital wall controllers and dedicated remote mobile applications for user-facing volume and source selection.

Applications

Divisible Banquet Halls: Configures independent zone control or combined background music streams depending on physical room partition layouts.
Multi-Floor Retail Stores: Drives localized source routing, corporate messaging, and background music across distinct customer zones.
Large Restaurants and Sports Bars: Coordinates multiple high-definition audio feeds (such as TVs, stream feeds, and live mics) across bars, dining rooms, and outdoor spaces.
Corporate Conference Complexes: Automates microphone prioritization and localized audio paths for larger presentation areas and training facilities.

Specifications

DSP Section	Signal Processor/CPU: 32-Bit Fixed / Floating-Point DSP + ARM, 456 MHz Maximum Calculation: 3.6 GIPS / 2.7 GFLOPS Audio Latency: 900 μs (Analog In to Analog Out) A/D and D/A Converters: 24-Bit Sample Rate: 48 kHz
Audio Performance	Frequency Response: 20 Hz to 20 kHz (+0.3 / -0.5 dB) THD+N: <0.01 % at +4 dBu (A-Weighted / 20 Hz to 20 kHz) Channel Separation (Crosstalk): <-105 dB at +4 dBu Input and Output Level, 1 kHz Dynamic Range: >115 dB A-weighted 20 Hz to 20 kHz, Analog Through
Analog Audio Inputs	Input Channels: 12 Analog Inputs (Four Unbalanced, Eight Balanced) Connectors: Inputs 1-4: RCA pairs Inputs 5-11: 3-Pin Euroblock Input 12: 4-Pin Euroblock with Dedicated GPI for Paging Types: Inputs 1-4: Unbalanced, Mono-Summed Inputs 5-11: Balanced, Mic/Line Input 12: Balanced Mic/Line or 600-Ohm Paging Input Sensitivity Options (via Configuration Utility): Inputs 1-4: -10 dBV Inputs 5-11: -70 / -60 / -50 / 0 /+4 dBu, -10 dBV with Selectable Phantom Power Input 12: -70 / -60 / -50 / 0 /+4 dBu, -10 dBV with Selectable Phantom Power Input Impedance: 12 Kilohms at 1 kHz (with or without Phantom Power Active) Maximum Input Level: +24 dBu (THD+N <=0.3%, 20 Hz to 20 kHz, 0 dB Gain) Equivalent Input Noise: <-119 dBu (22 Hz – 20 kHz, 150-Ohm Input, 64 dB Gain) Phantom Power: +48 V, Open Circuit, 10 mA Max per Channel, Selectable per Input, 80 mA Max Across All Channels
Analog Audio Outputs	Output Channels: 12 (4 Analog, 8 Digital via AmpLink) Connectors: Analog Outputs 1-3: 3-Pin Euroblock Analog Output 4: 3-Pin Euroblock Digital Outputs: RJ-45 Type: Analog Outputs 1-3: Balanced Line Level Analog Output 4: Balanced Line Level, or Fully Isolated Output for Music On-Hold for 600-Ohm Telephone Systems (Activated in Configuration Utility) Digital Outputs: 48 kHz, 8-Channel Digital Audio Over AmpLink Output Impedance: 66 Ohms Maximum Output Level: +24 dBu (THD+N <=0.3%, 22 Hz to 20 kHz)
Control Inputs	Inputs (Control): 8 Digital Inputs, 2 Kilohms Internal Pull-Up Resistor to 5 V, Green 0.15″ / 3.8 mm Pitch Connector (9-Pin) Mute (Control): 1 Digital Input, 2 Kilohms Internal Pull-Up Resistor to 5 V, Black 0.15″ / 3.8 mm Pitch Connector (2-Pin) Digital Input Voltage: 0 V to 3.3 V (Threshold Voltage = 1.6 V)
Control Output	Outputs (Control): 1 Digital Output, Orange 0.15″ / 3.81 mm Pitch Connector (2-Pin) Output Voltage High: 8 V (Open Circuit), 2.5 V at 10 mA; Low: <1 V at 100 mA, Push Pull Output Current 10 mA Source, 100 mA sink (24 VDC max external supply voltage)
Indicators & Controls	LED Status Indicators: Power/Status, Signal, Ethernet, AmpLink Audio Signal Indication: Green (-60 to -20 dBFS), Yellow (-20 to -2 dBFS), Red (-2 dBFS to Clip)
General	Configuration Software: Web Browser Based Configuration Utility Network Control: Ethernet (RJ-45), 1 Gbps
Operating Temperature	32 to 104°F / 0 to 40°C
Cooling System	Active, Side Venting with Fan
Power	Mains Voltage: 85 to 264 VAC, 50/60 Hz Mains Connector: IEC 60320-C14 (Inlet) Power Dissipation: ~22 W (75 BTU/Hr, 19 kcal/hr)
Dimensions	1.7 x 19.0 x 8.5″ / 4.3 x 48.3 x 21.6 cm
